[HWI-T621H-Z] HIKVISION HiWatch Bullet Compact IP Camera 2MP
- 1/2.7" progressive scan CMOS
- 1920 × 1080@30fps
- 2.8 mm to 12 mm motorized varifocal lens
- H.265+, H.265, H.264+, H.264
- Dual stream
- Digtal WDR (Wide Dynamic Range)
- 3D DNR (Digital Noise Reduction)
- Up to 30 m IR range
- PoE (Power over Ethernet)
- IP67
Camera | |
Appearance | Turret |
Image Sensor | 1/2.7" progressive scan CMOS |
Min. Illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0.02 Lux @ (F1.6, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s |
Slow Shutter | Yes |
Auto-Iris | No |
Day & Night | IR cut filter |
Digital Noise Reduction | 3D DNR |
WDR | DWDR |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens | |
Focal Length | 2.8 mm to 12 mm |
Aperture | F1.6 |
Focus | Auto |
Angle of view | Horizontal FOV 108.5° to 33.2°, vertical FOV 57.5° to 18.8°, diagonal FOV 130° to 38° |
Lens Mount | Ø 14 |
IR | |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Compression Standard | |
Video Compression | Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 8 Mbps |
Smart Feature-Set | |
Region of Interest | 1 fixed region for main stream and sub-stream |
Image | |
Resolution | 2MP |
Main Stream Max. Frame Rate | 50Hz: 25fps (1920 × 1280, 1280 × 960, 1280 × 720) 60Hz:30fps (1920 × 1280, 1280 × 960, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Enhancement | BLC, 3D DNR |
Image Setting | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, scheduled, day, night |
Network | |
Alarm Trigger | Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full |
Network Storage | Support built-in microSD/SDHC/SDXC card (128G), local storage and ANR |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
General Function | One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users 3 levels: Administrator, Operator, and User |
Client | iVMS-4200, Hik-Connect |
Web Browser | IE8+, Chrome 31.0-44, Firefox 30.0-51 |
Interface | |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
On-board storage | Built-in microSD/SDHC/SDXC slot, up to 128 GB |
Reset Button | Yes |
General | |
Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Power Consumption | 12 VDC, 0.9 A, Max: 10.5 W PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, Max: 12 W |
Ingress Protection level | IP67 |
Material | Camera body: metal, bottom base: plastic |
Dimensions | Camera: Ø 129.4 mm × 116.4 mm (5.1" × 4.6") With package: 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
Weight | Camera: 560 g (1.2 lb.) With package: 850g (1.9 lb.) |
