[HWI-D640H-Z] HIKVISION Turret Compact IP Camera Hiwatch 4MP IR30m2.8mm to 12mm H265+ POE IP67
- 1/3" progressive scan CMOS
- 2560 × 1440@20fps
- 2.8 mm to 12 mm motorized varifocal lens
- H.265+, H.265, H.264+, H.264
- Dual stream
- 120 dB WDR (Wide Dynamic Range)
- 3D DNR (Digital Noise Reduction)
- Up to 30 m IR range
- Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
- PoE (Power over Ethernet)
- IP67, IK10
Camera | |
Appearance | Dome |
Image Sensor | 1/3" progressive scan CMOS |
Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON) |
Shutter Speed | 1/3 s to 1/100, 000 s, support slow shutter |
Slow Shutter | Yes |
Auto-Iris | No |
Day & Night | IR cut filter |
Digital Noise Reduction | 3D DNR |
WDR | 120 dB |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 360° |
Lens | |
Focal Length | 2.8 to 12 mm |
Aperture | F1.6 |
Focus | Auto |
Angle of view | Horizontal field of view: 98° to 28°, Vertical field of view: 51° to 16°, Diagonal field of view: 115° to 32° |
Lens Mount | Φ14 |
IR | |
IR Range | Up to 30 m |
Wavelength | 850 nm |
Compression Standard | |
Video Compression | Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.264+ | Main stream supports |
H.265 Type | Main Profile |
H.265+ | Main stream supports |
Video Bit Rate | 32 Kbps to 8 Mbps |
Smart Feature-Set | |
Region of Interest | 1 fixed region for main stream and sub-stream |
Image | |
Resolution | 4MP |
Main Stream Max. Frame Rate | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Sub-stream Max. Frame Rate | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Image Enhancement | BLC, 3D DNR |
Image Setting | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Day/Night Switch | Auto, scheduled |
Network | |
Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login |
Network Storage | Support micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
General Function | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
Simultaneous Live View | Up to 6 channels |
User/Host | Up to 32 users |
Client | iVMS-4200, Hik-Connect |
Web Browser | IE8+, Chrome 31.0-44, Firefox 30.0-51 |
Interface | |
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
On-board storage | Built-in micro SD/SDHC/SDXC card slot, up to 128 GB |
Reset Button | Yes |
General | |
Operating Conditions | -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing) |
Power Supply | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
Power Consumption | 12 VDC, 0.8 A, max: 10 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max: 12 W |
Ingress Protection level | IP67 |
Impact Protection | IK10 |
Material | Metal & Plastic |
Dimensions | Camera: Ø 141.2 mm × 99.6 mm (Ø 5.6" × 3.9") With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1") |
Weight | Camera: approx. 820 g (1.8 lb.) With package: approx. 1200 g (2.6 lb.) |
HWI-D640H-Z
Data sheet
- Píxel
- 4 Mpx
- Material
- Metal
- Zoom
- Motorized
